Showing all 11 results
Price range: 5,99 $ through 75,00 $- Length : 10 ‘ (3.00Meters)
- Beam : 55″ (1.4 Meters)
- Depth: 8″ (20 Cm)
- Engine: 10-20 HP Long Shaft (20″ transom notch)
- Dry Hull Weight: 460 Lbs. (208 Kg.)
- Max Gross Load: 2 Persons @75kg = 150kg
- (Class “D”)
10 Foot Aluminum Utility Skiff Plans
Price range: 5,99 $ through 75,00 $ Select options This product has multiple variants. The options may be chosen on the product pageQuick View
53,00 $- Length : 10 ‘ (3.00Meters)
- Beam : 55″ (1.4 Meters)
- Depth: 8″ (20 Cm)
- Engine: 10-20 HP Long Shaft (20″ transom notch)
- Dry Hull Weight: 460 Lbs. (208 Kg.)
- Max Gross Load: 2 Persons @75kg = 150kg
- (Class “D”)
10 Foot Plywood Utility Skiff Plans
53,00 $ Select options This product has multiple variants. The options may be chosen on the product pageQuick View
Price range: 5,99 $ through 130,00 $- Length : 11 ‘ 4″ (3.45 Meters)
- Beam : 65″ (1.65 Meters)
- Depth: 4″ (16 Cm)
- Engine: 5-20 HP Long Shaft (20″ transom notch)
- Dry Hull Weight: 319 Lbs. (145kg.)
- Max Gross Load: 3 Persons @75kg = 150kg
- (Class “C”)
11 Foot Aluminum Utility Skiff Plans
Price range: 5,99 $ through 130,00 $ Select options This product has multiple variants. The options may be chosen on the product pageQuick View- 90,00 $
- Length : 11 ‘ 4″ (3.45 Meters)
- Beam : 65″ (1.65 Meters)
- Depth: 4″ (16 Cm)
- Engine: 5-20 HP Long Shaft (20″ transom notch)
- Dry Hull Weight: 319 Lbs. (145kg.)
- Max Gross Load: 3 Persons @75kg = 150kg
- (Class “C”)
11 Foot Plywood Utility Skiff Plans
90,00 $ Select options This product has multiple variants. The options may be chosen on the product pageQuick View
Price range: 14,90 $ through 235,00 $- Hull length: 17′ (5,18m)
- Hull width 80″ (2,03m)
- Chine Width 60″ (1,52m)
- Max MPH 30-32 mph
- Side Depth 29,5″ (75 cm)
- Cockpit Depth 23″ (58 cm)
- Fuel Capacity – Portable
- Deadrise 4,75°
- Dry hul weight: 870 lbs (395 kg)
- Weight (Boat + max engine, dry) 1135 lbs (515 kg)
- Front Livewell Capacity: 17 Gal – 65 liters
- Front Livewell Length: 32″ (82 cm) Long
- Draft max. water line: 5″ – 7″ (12 – 19 cm)
- Displacement max: 1796 lbs (815 kg)
- Max Person weight 661 lbs (300 kg)
- Maximum Persons 4
- Design category „C”
- Transom inclination angle 12 degrees
- Transom Height: 20″ – 508mm (foot “L”)
- Outboard engine: 20 HP – 60 HP
1760 Aluminum Jon Boat Plans with side console
Price range: 14,90 $ through 235,00 $ Select options This product has multiple variants. The options may be chosen on the product pageQuick View
Price range: 5,99 $ through 75,00 $- Hull length: 6.0 m
- Hull width 2.2 m
- Dry hul weight: 350 kg
- Draft max. water line: 18 cm
- Displacement up to KLW: 1215 kg
- Crew: max 5 people
- Design category „C”
- Transom inclination angle 12 degrees
- Transom height 508mm (foot “L”)
- Outboard engine: max 60 HP
Downloadable version of plans. Instant Download After Purchase
20 Foot (6,0m) Plywood Jon Boat Plans
Price range: 5,99 $ through 75,00 $ Select options This product has multiple variants. The options may be chosen on the product pageQuick View
9,95 $- Technical data imperial
- Hull length: 8 foot 6 inch
- Hull width: 3 foot 8 inch
- Basic material list imperial: (full in plans file)
- 2 sheet plywood 48’x96″x1/4″
- 1 sheet plywood 48″x96″x1/2″
- Technical data metric:
- Hull length: 2,6 m
- Hull width 1,1 m
- Basic material list metric: (full in plans file)
- 2 sheet plywood 1250 x 2500 x 6mm
- 1 sheet plywood 1250 x 2500 x 12mm
8 foot 6 inch Plywood Row Boat
9,95 $ Select options This product has multiple variants. The options may be chosen on the product pageQuick View- Technical data imperial
99,00 $- Hull length: 11′ 10″ (3,6m)
- Hull width 50″ (1.27m)
- Chine Width 38″ (0.97m)
- Side Depth 17″ (43cm)
- Cockpit Depth 15 1/2″ (39cm)
- Fuel Capacity – Portable
- Deadrise 0.0° (flat bottom)
- Dry hul weight: 308 lbs (140 kg)
- Maximum Persons: 1-2
- Design category „D”
- Transom inclination angle 12 degrees
- Transom Height: 15″ – 38.1cm (foot “S”)
- Outboard engine: 5 HP – 10 HP
Classic – 1238 – Aluminum Jon Boat Plans – Flat Bottom
99,00 $ Select options This product has multiple variants. The options may be chosen on the product pageQuick View- 44,00 $
- Hull length: 11′ 10″ (3,6m)
- Hull width 50″ (1.27m)
- Chine Width 38″ (0.97m)
- Side Depth 17″ (43cm)
- Cockpit Depth 15 1/2″ (39cm)
- Fuel Capacity – Portable
- Deadrise 0.0° (flat bottom)
- Dry hul weight: 308 lbs (140 kg)
- Maximum Persons: 1-2
- Design category „D”
- Transom inclination angle 12 degrees
- Transom Height: 15″ – 38.1cm (foot “S”)
- Outboard engine: 5 HP – 10 HP
Classic – 1238 – Plywood Jon Boat Plans – Flat Bottom
44,00 $ Select options This product has multiple variants. The options may be chosen on the product pageQuick View
113,00 $- Hull length: 14′ (4.27m)
- Hull width 60″ (1.52m)
- Chine Width 48″ (1,22m)
- Side Depth 20″ (51cm)
- Cockpit Depth 19″ (48 cm)
- Fuel Capacity – Portable
- Deadrise 0.0° (flat bottom)
- Dry hul weight: 352 lbs (160 kg)
- Weight (Boat + max engine, dry) 617 lbs (280 kg)
- Draft max. water line: 2″ – 3″ (5-8 cm)
- Displacement 4″: 1029 lbs (467 kg)
- Displacement 3″: 626 lbs (284 kg)
- Max Person weight 496 lbs (225 kg)
- Maximum Persons: 2-3
- Design category „D”
- Transom inclination angle 12 degrees
- Transom Height: 15″ – 38.1cm (foot “S”) (foot L on demand)
- Outboard engine: 15 HP – 25 HP
Classic – 1448 – Aluminum Jon Boat Plans – Flat Bottom
113,00 $ Select options This product has multiple variants. The options may be chosen on the product pageQuick View- 54,00 $
- Hull length: 14′ (4.27m)
- Hull width 60″ (1.52m)
- Chine Width 48″ (1,22m)
- Side Depth 20″ (51cm)
- Cockpit Depth 19″ (48 cm)
- Fuel Capacity – Portable
- Deadrise 0.0° (flat bottom)
- Dry hul weight: 352 lbs (160 kg)
- Weight (Boat + max engine, dry) 617 lbs (280 kg)
- Draft max. water line: 2″ – 3″ (5-8 cm)
- Displacement 4″: 1029 lbs (467 kg)
- Displacement 3″: 626 lbs (284 kg)
- Max Person weight 496 lbs (225 kg)
- Maximum Persons: 2-3
- Design category „D”
- Transom inclination angle 12 degrees
- Transom Height: 15″ – 38.1cm (foot “S”) (foot L on demand)
- Outboard engine: 15 HP – 25 HP
Classic – 1448 – Plywood Jon Boat Plans – Flat Bottom
54,00 $ Select options This product has multiple variants. The options may be chosen on the product pageQuick View
